Sachs engine & gearbox

swiing® revival stud bolt M6 x 106 mm (10.9 strength)

Manufacturer: swiing® revival parts · Thread length: 12 mm · Thread length: 20 mm · Material: Steel · Surface: galvanized (blue) · Thread type: M6x1 (standard thread) · Total length: 106 mm · Puch OEM number: 360.1.10.034.1

Meteor piston ring 39.2 x 2 mm (FS)

Manufacturer: Meteor · Nominal diameter: 39 mm · Height: 2 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Thick piston ring: 1.65 mm · Pony OEM number: A1112 · Sachs OEM no.: 0215 003 105

Meteor piston ring 38.6 x 2 mm (FS)

Manufacturer: Meteor · Nominal diameter: 38 mm · Height: 2 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Thick piston ring: 1.6 mm

Cylinder head | Sachs 50/2

Number of fixing points: 4 pcs · Decompressor: Yes · Pony OEM number: A1069 · Pony OEM number: A1070 · Sachs OEM no.: 0213 104 006 · Sachs OEM no.: 0213 106 000

GPO rubber grommet ignition cable | Sachs 50/2 (A1922)

Manufacturer: GPO · Material: Rubber · Color: black · Pony OEM number: A1922 · Sachs OEM no.: 0260 018 100

Clutch lock plate | Sachs 50/2 & 503 (A1907)

Material: Steel · Area of application: Standard · Pony OEM number: A1907 · Sachs OEM no.: 0259 014 000

Meteor piston 38.6 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Ø outside piston (A): 38.55 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Nominal diameter: 38 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Ø piston pin (B): 12 mm · Piston ring height: 2 mm · Piston weight: 84 g · Pony OEM number: A2774 · Pony OEM number: A4359 · Sachs OEM no.: 0286 377 012 · Sachs OEM no.: 0286 378 006

Outer ring 23.5/31.5/6 Main shaft left | Sachs 502, 50/2, 50/3, 50/4, 503 (A1157)

Material: Steel · Surface: hardened & ground · Width: 6 mm · Ø inside: 23.5 mm · Ø outside: 31.5 mm · Pony OEM number: A1157 · Sachs OEM no.: 0232 049 000

Thrust washer 16.5/31.3/1 main shaft | Sachs 50/2, 503 (A1570)

Material: Steel · Surface: hardened & ground · Thickness: 1 mm · Ø inside: 16.5 mm · Ø outside: 31.3 mm · Pony OEM number: A1570 · Sachs OEM no.: 0244 078 000

GPO ball bearing countershaft | Sachs 50/2, 50/3, 50/4, 503 2AL/2BL (A2531)

Bearing type: Deep groove ball bearing · Manufacturer: GPO · Ball bearing closed: No · Bearing clearance: CN (standard) · Bearing cage: "-" Sheet steel cage ball-guided · Material: Steel · Surface: blank / oiled · Area of application: Standard · Ø inside: 15 mm · Thread type: MF20x1 (fine pitch thread) · Ø outside: 35 mm · Width: 8 mm · Width: 25.6 mm · Pony OEM number: A2531 · Sachs OEM no.: 0286 079 105

swiing® revival bearing press-on sleeve | Puch, Sachs

Nominal diameter inside: 17.5 mm · Ø inside: 17.6 mm · Ø outside: 25 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Total length: 86 mm

swiing® revival flame tube 28 / 22.7 mm original chrome | Sachs 503

Manufacturer: swiing® revival parts · Material: Steel · Surface: chrome-plated · Ø inside: 20 mm · Ø outside: 22.7 mm · Ø outside: 28 mm · Mounting type: Bride · Color: Chrome

NSK crankshaft bearing set | Sachs 50/2

Manufacturer: NSK · Manufacturer: Sachs · Number of components: 4 pcs

GPO clutch plates (2 pcs.) | Sachs 50/2, 503 2AL/2BL (A3887)

Manufacturer: GPO · Material: Composite materials · Material: Steel · Thickness: 3.3 mm · Ø inside: 29.6 mm · Ø inside: 35.6 mm · Recording type: Interlocking · Area of application: Standard · Number of slats: 2 pcs · Ø outside: 93 mm · Pony OEM number: A3887 · Sachs OEM no.: 0659 010 006

Meteor piston ring 38 x 1.5 mm (IS)

Manufacturer: Meteor · Height: 1.5 mm · Nominal diameter: 38 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Thick piston ring: 1.6 mm

Meteor piston 39.2 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Ø outside piston (A): 39.2 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Nominal diameter: 38 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Ø piston pin (B): 12 mm · Piston ring height: 2 mm · Piston weight: 88 g · Pony OEM number: A2776 · Sachs OEM no.: 0286 377 014

Meteor piston 38 mm #C | Sachs 503 AB/AC

Manufacturer: Meteor · Ø outside piston (A): 37.98 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Nominal diameter: 38 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Ø piston pin (B): 12 mm · Piston ring height: 1.5 mm · Tolerance group: C · Piston weight: 75 g · Pony OEM number: A5685C · Sachs OEM no.: 0286 382 306

Meteor piston ring 38.9 x 2 mm (FS)

Manufacturer: Meteor · Nominal diameter: 39 mm · Height: 2 mm · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Thick piston ring: 1.6 mm

swiing® revival needle roller bearing 12/15/14.2 original

Bearing type: Needle sleeve · Ø inside: 12 mm · Manufacturer: swiing® revival parts · Bearing cage: Sheet steel cage · Width: 14.2 mm · Ø outside: 15 mm · Dimension needle bearing: 12/15 x 14.2 · Alternative version of the Pony OEM number: A4222 · Tomos OEM number: 035548 · Alternative version of the Sachs OEM number: 0232 155 001

Engine mount set | Sachs 504/1

Manufacturer: NTN · Number of components: 5 pcs · Area of application: Standard

NTN 6202 Ball bearing 15/35/11 | Sachs 503 ADV/AB, 504, 535 (A1165)

Bearing type: Deep groove ball bearing · Stock number: 6202 · Ø inside: 15 mm · Ø outside: 35 mm · Width: 11 mm · Manufacturer: NTN · Bearing clearance: CN (standard) · Bearing cage: "-" Sheet steel cage ball-guided

Engine bearing set | Sachs 504/2

Manufacturer: NTN · Number of components: 5 pcs · Area of application: Standard

Woodruff key KW/Transmission | Sachs (A1674)

Total length: 9.3 mm · Width: 3 mm · Height: 3.8 mm · Manufacturer: Sachs · Material: Steel · Pony OEM number: A1674 · Sachs OEM no.: 0246 005 000

GPO flame tube 28 mm | Sachs 50/2, 50/3

Color: Chrome · Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Ø outside: 28 mm · Ø inside: 25.6 mm · Total length: 390 mm · Mounting type: Union nut · Ø External connection: 32.4 mm

NewFren clutch 1st gear | Sachs 50/2, 503 AB/AC/ADV/ABL (A5496/A5639)

Manufacturer: NewFren · Number of jaws: 3 pcs · Area of application: Original · Pony OEM number: A2739 · Pony OEM number: A5639 · Sachs OEM no.: 0284 026 500 · Sachs OEM no.: 0286 349 000

Fan wheel Occ. | Sachs 503

Manufacturer: Sachs · Material: Plastic · Ø mounting hole: 6 mm · Number of fixing points: 3 pcs · Pony OEM number: A2161 · Sachs OEM no.: 0266 002 000

Small gearwheel 24 teeth | Sachs 50/4

Material: Steel · Surface: Hardened · Toothing type: straight toothed · Number of teeth: 24 pcs · Ø inside: 23 mm · Ø inside: 29 mm · Ø outside: 46 mm

Large derailleur wheel 27 teeth | Sachs 50/4

Material: Steel · Surface: Hardened · Toothing type: straight toothed · Number of teeth: 27 pcs · Ø inside: 23 mm · Ø inside: 29 mm · Ø outside: 52.5 mm

16 mm circlip pedal start mechanism Sachs

Fuse type: Outside · Nominal diameter: 16 mm · Manufacturer: Sachs

swiing® revival plain bearing countershaft | Sachs 50/2, 503 2AL/2BL

Manufacturer: swiing® revival parts · Material: special bearing bronze · Ø inside: 14 mm · Nominal diameter inside: 14 mm · Ø outside: 15 mm · Total length: 25 mm

swiing® revival plain bearing with collar countershaft | Sachs 50/2 (A1186)

Ø inside: 13 mm · Nominal diameter inside: 13 mm · Ø outside: 16 mm · Ø Bundle: 18 mm · Total height: 14 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze · Pony OEM number: A1186 · Sachs OEM no.: 0232 153 001

Shim 15/21/0.5 Crankshaft E15 Bearing | Sachs

Ø inside: 15 mm · Nominal diameter inside: 15 mm · Ø outside: 21 mm · Thickness: 0.5 mm · Manufacturer: Sachs · Material: Steel · Surface: blank / oiled · Pony OEM number: A1680 · Sachs OEM no.: 0246 009 001

GPO sprocket 13 teeth with chrome cone | Sachs 50/2

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Number of teeth: 13 pcs · Thickness: 4.3 mm · Recording type: Cone mounting · Total thickness: 15 mm · Alternative version of the Pony OEM number: A1273 · Alternative version of the Sachs OEM number: 0236 093 100

GPO sprocket 15 teeth with cone chrome | Sachs 50/2

Surface: chrome-plated · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: GPO · Material: Steel · Number of teeth: 15 pcs · Thickness: 4.3 mm · Recording type: Cone mounting · Total thickness: 15 mm

GPO sprocket 14 teeth with cone chrome | Sachs 50/2

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Number of teeth: 14 pcs · Thickness: 4.3 mm · Recording type: Cone mounting · Total thickness: 15 mm

GPO sprocket 11 - 16 teeth chrome | Sachs 503, 502, 50/2, 50/3, 50/4 (your choice)

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Chain pitch: 1/2" x 3/16" · Chain type: 415H · Number of teeth: 11 pcs · Number of teeth: 12 pcs · Number of teeth: 13 pcs · Number of teeth: 14 pcs · Number of teeth: 15 pcs · Number of teeth: 16 pcs · Thickness: 4.3 mm · Recording type: Ø15 x SW12 · Total thickness: 5.8 mm

Piston pin extractor

Area of application: Special tool · Material: Steel · Surface: chrome-plated · Width: 85 mm · Total length: 200 mm · Ø Pin: 5 mm · Thread type: MF8x1 (fine pitch thread) · Thread length: 95 mm

Stud bolt inlet/outlet M8 x 30 mm

Material: Steel · Surface: burnished · Thread type: M8x1.25 (standard thread) · Total length: 30 mm · Thread length: 10 mm

swiing® revival clutch plate | Sachs 503 AB, ABL (A5640)

Manufacturer: swiing® revival parts · Material: Steel · Surface: coated · Ø inside: 19.1 mm · Ø outside: 60.5 mm · Area of application: Standard · Pony OEM number: A5640 · Sachs OEM no.: 0284 032 200

Meteor piston 38 mm type E | Sachs 503 ADV

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 54 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: E · Piston weight: 76 g

Meteor piston 38 mm #A | Sachs 505

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.97 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: A · Piston weight: 79 g

Meteor piston 38 mm #B | Sachs 505

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.98 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: B · Piston weight: 79 g

Flame tube 28 mm sidepipe | Sachs 50/2, 50/3

Material: Steel · Surface: chrome-plated · Ø inside: 25.6 mm · Ø outside: 28 mm · Color: Chrome · Mounting type: Union nut

Flame tube 32 mm sidepipe | Sachs 50/2, 50/3

Material: Steel · Surface: chrome-plated · Ø inside: 29.3 mm · Ø outside: 32 mm · Color: Chrome · Mounting type: Union nut

Meteor piston 38 mm #C | Sachs 505

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.99 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: C · Piston weight: 79 g

Meteor piston 38 mm #D | Sachs 505

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 50.5 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Tolerance group: D · Piston weight: 78 g

Meteor piston 38 mm ADV type A | Sachs 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 54 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: A · Piston weight: 78 g

Meteor piston 38 mm type B | Sachs 503 ADV

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.97 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 54 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: B · Piston weight: 76 g

Meteor piston 38 mm type C | Sachs 503 ADV

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.98 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 54 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: C · Piston weight: 76 g

Meteor piston 38 mm type D | Sachs 503 ADV

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.99 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 54 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: D · Piston weight: 77 g
