Catalog with complete exploded views of the Sachs Zweigang 50/2 MLC and 50/AMLC engines.
The complete engine from cylinder to carburetor is shown in helpful exploded views. Each individual component is provided with part number, spare part number, weight and installation location.
A helpful catalog from 1972 with 23 interesting double pages.
Details
| Material | Paper |
| DIN format | A5 |
| Number of pages | 23 pcs |
Suitable for the following models
| Sachs | 502 (Saxonette) - AML 50/2 - ML CH (0.8 PS) |
