Siggnature flange Ø 30 mm for Stage6 RT-PWK carburetor

swiing® revival stud bolt inlet/outlet M6 x 30 mm (10.9 strength)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Diameter: 5.95 mm · Thread type: M6x1 (standard thread) · Total length: 30 mm · Thread length: 12 mm · Strength class: 10.9

Stage6 R/T RT-PWK 28 mm carburetor *Black Edition*

Manufacturer: Stage6 R/T · Surface: varnished · Color: black · Mounting type: Flange · Mounting type: Plug connection · Carburetor type: RT-PWK · Nozzle thread: M5x0.8 (standard thread) · Nominal diameter: 28 mm · Area of application: Tuning · Ø Air filter connection: 50 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Choke control: Hand choke

Stage6 R/T RT-PWK 24 mm carburetor Stage6 *Black Edition*

Manufacturer: Stage6 R/T · Surface: varnished · Color: black · Mounting type: Flange · Mounting type: Plug connection · Carburetor type: RT-PWK · Nozzle thread: M5x0.8 (standard thread) · Nominal diameter: 24 mm · Area of application: Tuning · Ø Air filter connection: 50 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Choke control: Hand choke

Stage6 R/T RT-PWK 21 mm carburetor *Black Edition*

Manufacturer: Stage6 R/T · Surface: varnished · Color: black · Mounting type: Flange · Mounting type: Plug connection · Carburetor type: RT-PWK · Nozzle thread: M5x0.8 (standard thread) · Nominal diameter: 21 mm · Area of application: Tuning · Ø Air filter connection: 50 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Choke control: Hand choke

Stage6 R/T RT-PWK 26 mm carburetor *Black Edition*

Manufacturer: Stage6 R/T · Surface: varnished · Color: black · Mounting type: Flange · Mounting type: Plug connection · Carburetor type: RT-PWK · Nozzle thread: M5x0.8 (standard thread) · Nominal diameter: 26 mm · Area of application: Tuning · Ø Air filter connection: 50 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Choke control: Hand choke

Flange nut M6 galvanized (strength 10)

Material: Steel · Surface: galvanized (blue) · Nut type: Flange nut · Thread type: M6x1 (standard thread) · Height: 9 mm · Drive: External hexagon · Width across flats SW: 10 mm · Ø outside: 13.9 mm · Area of application: Standard · Strength class: 10

Flange nut M6 self-locking Inox

Material: Chrome steel (stainless steel) · Nut type: Flange nut · Nut type: Self-securing nut · Thread type: M6x1 (standard thread) · Drive: External hexagon · Height: 9 mm · Width across flats SW: 10 mm

Magura cable holder

Ø Nipple hole: 6.2 mm · Manufacturer: Magura · Material: Brass · Surface: nickel-plated · Color: silver · Ø Cable bushing: 4 mm · Ø outside: 8 mm · Ø Bundle: 10 mm · Total length: 14.5 mm · Area of application: Standard

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Mounting type: Union nut · Thread type: MF12x1 (fine pitch thread) · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Reserve level: 70 mm

Magura gas cable clamp / deco cable clamp Ø 5 x 6 mm

Manufacturer: Magura · Material: Brass · Material: Steel · Surface: nickel-plated · Thread type: M4x0.7 (standard thread) · Ø Cable bushing: 1.6 mm · Drive: Slot · Ø outside: 5 mm · Screw head: Lens head · Total length: 6 mm · Thread length: 4 mm · Number of components: 2 pcs

Lusito throttle twist grip

Manufacturer: Lusito · Material: Rubber · Housing material: Aluminum · Surface: powder-coated · Material lever: Aluminum · Color: black · Color: silver · Ø inside: 22 mm · Total length: 150 mm · Number of components: 3 pcs

Lusito deco/brake lever

Manufacturer: Lusito · Material: Rubber · Housing material: Aluminum · Surface: powder-coated · Material lever: Aluminum · Color: black · Color: silver · Mounting type: Screws · Ø inside: 22 mm · Total length: 145 mm

Magura adjusting screw brake short

Manufacturer: Magura · Material: Brass · Surface: nickel-plated · Color: silver · Thread type: MF6x0.75 (fine pitch thread) · Ø shaft: 6.1 mm · Drive: Knurled screw · Total length: 31 mm · Total length: 40 mm · Ø External head: 9.15 mm · Thread length: 15 mm · Shank length: 6.9 mm

Magura set screw M6 tightened

Total length: 30 mm · Slotted: No · Manufacturer: Magura · Material: Brass · Surface: nickel-plated · Thread type: M6x1 (standard thread) · Thread length: 18 mm

Stop button with cable (closer)

Housing material: Plastic · Substructure material: Steel · Ø Handlebars: 22 mm · Functions: Motor stop · Number of cables: 2 pcs · Cable length: 750 mm

swiing 15 mm carburetor tuning camouflaged | Puch

Manufacturer: swiing · Material: Aluminum · Mounting type: Plug connection clamped · Carburetor type: SRE · Width: 50 mm · Nozzle thread: M3.5x0.6 (standard thread) · Ø fuel hose connection: 6 mm · Nominal diameter: 15 mm · Ø Internal connection: 20 mm · Total length: 66 mm · Nozzle size: 62 · Ø Inside entrance: 15 mm · Height: 95 mm · Area of application: Tuning · Ø Output inside: 15 mm · Ø Air filter connection: 20 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle block: 2.17 · Camouflaged: Yes · Clamping screw torque (max.): 4 N/m

swiing 15 mm carburetor set camouflaged | Puch E50

Nominal diameter: 15 mm · Manufacturer: swiing® ingenious parts · Area of application: Tuning · Carburetor type: SRE · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle size: 62 · Ø Inside entrance: 15 mm · Ø Internal connection: 20 mm · Ø Output inside: 15 mm · Ø Air filter connection: 20 mm · Hole spacing inlet: 38 mm · Ø fuel hose connection: 5 mm · Ø fuel hose connection: 6 mm · Mounting type: Plug connection clamped · Mounting type: Stud bolts & nuts · Choke control: Hand choke · Camouflaged: Yes · Clamping screw torque (max.): 4 N/m
