Repair manual for 2-speed Sachs 505 engines.
This super A4 catalog with 62 pages contains a lot of interesting information.
Everything about the engine is described in detail with revision instructions, many pictures and important facts.
The following things are also explained in detail: technical data, special tools, engine, inspection work, carburetor and the electrical system.
Catalog is trilingual. German, English and French.
Details
| Material | Paper |
| DIN format | A4 |
| Number of pages | 62 pcs |
| Component group Carburetor | Carburetor complete, Spraying, Sealing, revising |
Suitable for the following models
| Sachs | 505 (mit Tretwelle) - 2 A (HG) |
