Pulse coil | Piaggio Ciao, SI, Bravo, Boxer

swiing® ingenious puller flywheel | Piaggio Ciao, SI, Bravo, Boxer

Width across flats (trigger): 10 mm · Width across flats (trigger): 18 mm · Width across flats Screw: 19 mm · Manufacturer: swiing® ingenious parts · Area of application: (Dis)assembly tool · Material: Steel · Surface: blackened · Surface: blue galvanized · Thread type: MF12x1.5 (fine pitch thread) · Thread type: MF17x1 (fine pitch thread) · Diameter: 12 mm · Diameter: 24 mm · Total length: 100 mm · Number of components: 2 pcs

CIF impulse coil (1A quality) | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: CIF · Area of application: Original · Area of application: Standard · Number of fixing points: 2 pcs · Mounting type: Screws · Hole spacing: 50 mm

Wedge 12.1x4.9x3 mm

Total length: 12.5 mm · Width: 3 mm · Height: 4.9 mm · Material: Steel

Set light coil impulse coil | Piaggio Ciao, SI, Bravo, Boxer

Material: Steel · Light coil voltage: 6 V · Tension: 6 V · Ø cable: 0.8 mm · Ø Internal flywheel: 90 mm · Mounting type: Screws · Area of application: Original · Area of application: Standard · Number of fixing points: 2 pcs

GPO breaker without cable (version 2.0) | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Area of application: Original · Area of application: Standard · Material: Steel · Cable available: No · Ø axle: 5 mm · Number of fixing points: 1 pcs · Ø mounting hole: 5 mm · Piaggio spare part no.: 103133

swiing® revival condenser with cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: swiing® revival parts · Area of application: Original · Area of application: Standard · Capacity: 0.28 µF · Mounting type: Tab for screwing · Connection type: Cable for screwing · Ø outside: 18 mm · Ø mounting hole: 4.4 mm · Height: 26 mm · Piaggio spare part no.: 102939

Flywheel puller | Piaggio Ciao, SI, Bravo, Boxer

Width across flats (trigger): 19 mm · Width across flats Screw: 18 mm · Manufacturer: Quenching · Pull-off depth inside: 68 mm · Material: Steel · Surface: burnished · Surface: galvanized · Diameter: 12.9 mm · Thread type: MF17x1 (fine pitch thread) · Number of components: 2 pcs · Total length: 36.5 mm · Area of application: (Dis)assembly tool

Flywheel breaker ignition incl. coils | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Quenching · Material: Aluminum · Material: Steel · Tension: 6 V · Direction of rotation: right · Ø Internal flywheel: 92 mm · Ø Flywheel outside: 141 mm · Weight: 1300 g · Area of application: Standard

NGK B7HS spark plug short thread

Manufacturer: NGK · Candle thread type: short · Thread type: MF14x1.25 (fine pitch thread) · Spark plug socket: M4 · Spark plug socket: SAE · Suppressed: No · Width across flats SW: 21 mm

GPO Pulse coil | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Tension: 6 V · Ø mounting hole: 4.6 mm · Ø Internal flywheel: 91 mm · Hole spacing: 50 mm · Mounting type: Screws · Width: 23.8 mm · Total length: 80 mm · Height: 23.8 mm · Area of application: Standard · Number of fixing points: 2 pcs

GPO ignition cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Material: Copper · Material: Rubber · Color: black · Color: gray · Number of cables: 1 pcs · Tension: 6 V · Tension: 12 V · Cable length: 450 mm · Area of application: Standard · Piaggio spare part no.: 149504

EFFE breaker without cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: EFFE · Area of application: Original · Area of application: Standard · Material: Steel · Cable available: No · Ø mounting hole: 4.5 mm · Ø axle: 5 mm · Number of fixing points: 1 pcs · Piaggio spare part no.: 103133

EFFE Condenser with cable | Piaggio Ciao, SI, Bravo, Boxer

Height: 26 mm · Manufacturer: EFFE · Ø outside: 18 mm · Area of application: Original · Area of application: Standard · Capacity: 0.26 µF · Mounting type: Tab for screwing · Connection type: Cable for screwing · Ø mounting hole: 4.4 mm · Piaggio spare part no.: 102939

Lubricating felt flywheel / contact breaker ignition

Color: white · Area of application: Original · Material: Felt · Surface: raw · Pony spare part no.: A4665 · Sachs spare part no.: 2865 008 000

CIF intermediate disk flywheel / clutch bell | Piaggio Ciao, SI, Bravo Boxer

Nominal diameter: 12 mm · Manufacturer: CIF · Material: Steel · Surface: blue galvanized · Ø inside: 12 mm · Ø outside: 23 mm · Total length: 5 mm · Ø Bundle: 16.3 mm

Wedge 12.1x4.9x3 mm

Total length: 12.5 mm · Width: 3 mm · Height: 4.9 mm · Material: Steel

GPO breaker without cable (version 2.0) | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Area of application: Original · Area of application: Standard · Material: Steel · Cable available: No · Ø axle: 5 mm · Number of fixing points: 1 pcs · Ø mounting hole: 5 mm · Piaggio spare part no.: 103133

swiing® revival condenser with cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: swiing® revival parts · Area of application: Original · Area of application: Standard · Capacity: 0.28 µF · Mounting type: Tab for screwing · Connection type: Cable for screwing · Ø outside: 18 mm · Ø mounting hole: 4.4 mm · Height: 26 mm · Piaggio spare part no.: 102939

Wedge flywheel / torque converter bell Vario | Piaggio Ciao, SI, Bravo, Boxer

Material: Steel · Total length: 12.1 mm · Width: 3 mm · Height: 4.9 mm

GPO light coil | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Ø mounting hole: 4.4 mm · Hole spacing: 50 mm · Mounting type: Screws · Area of application: Original · Area of application: Standard · Number of fixing points: 2 pcs

GPO screw set ignition galvanized | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Material: Steel · Surface: blue galvanized · Drive: Cross recess · Drive: Slot · Screw head: Cylinder head · Screw head: Panhead · Number of components: 14 pcs · Area of application: Standard
