Locking plate Ø 10 mm pinion | Kreidler

BERU spark plug connector / 1 kΩ interference suppressed

Manufacturer: BERU · Material: Sheet metal (steel) · Spark plug socket: M4 · Cable available: No · Suppressed: Yes · Resistance: 1000 Ω · Ø cable: 5 mm · Ø cable: 7 mm · Color: silver · Pony spare part no.: A2099 · Sachs spare part no.: 0265 100 00

Airsal 45 mm cylinder kit 70 ccm camouflaged | Puch

Nominal diameter: 45 mm · Manufacturer: Airsal · Material: Cast aluminum · Area of application: Tuning · Camouflaged: Yes · Surface: sandblasted · Crankshaft stroke: 43 mm · Displacement: 70 ccm · Ø piston pin (B): 12 mm · Hole spacing inlet: 38 mm · Ø cylinder neck: 48 mm · Ø outlet inside: 25 mm · Inlet window: 23.5 / 20 x 15 · Thread inlet: M6x1 (standard thread) · Hole spacing outlet: 42 mm · Decompressor: Yes · Outlet type: straight · Thread outlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44

swiing® revival gasket set | Puch X30 Velux

Manufacturer: swiing® revival parts · Area of application: Standard · Number of components: 11 pcs · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44

Dell'Orto 19 mm PHBG CS carburetor hand choke

Manufacturer: Dell'Orto · Material: Aluminum · Camouflaged: No · Color: black · Width: 70 mm · Carburetor type: PHBG CS · Nominal diameter: 19 mm · Total length: 82 mm · Ø Internal connection: 24 mm · Ø without reducing sleeve: 26 mm · Ø Inside entrance: 19 mm · Ø Output inside: 19 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 32 mm · Ø Air filter connection: 60 mm · Height: 124 mm · Air filter connection thread: MF32x1.25 (fine pitch thread) · Area of application: Racing · Area of application: Tuning · Ø fuel hose connection: 5.4 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Choke control: Hand choke · Choke nozzle size: 60 · Nozzle thread: M5 · Nozzle size: 75 · Size of secondary nozzle: 45

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Thread type: MF12x1 (fine pitch thread) · Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Mounting type: Union nut · Ø fuel hose connection: 6 mm · Reserve level: 70 mm

M12 locking plate 2 tabs

Ø inside: 12.7 mm · Material: Steel · Thread size: M12 · Width: 6 mm · Number of lobes: 2 pcs · Thickness: 1 mm · Width 2: 9 mm

EBR standard fork black | Piaggio Ciao

Thread type: FG25.4 (1" 24G) · Manufacturer: EWC · Material: Steel · Surface: varnished · Adjustable: No · Thread length: 58 mm · Ø outer head tube: 25.5 mm · Ø head tube inside: 21 mm · Head tube length: 200 mm · Color: black · Fork bridge - center wheel axle: 355 mm · Total length: 580 mm

GPO piston 41 mm (12 mm KoBo) | Puch X30 Velux fan-cooled

Nominal diameter: 41 mm · Manufacturer: GPO · Ø outside piston (A): 40.94 mm · Ø piston pin (B): 12 mm · Compression height (C): 23.2 mm · Curvature (D): 3.7 mm · Total piston height (E): 49.3 mm · Number of piston rings (F): 2 pcs · Piston ring mold: L-ring · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring impact: Internal fuse (IS)

NSK BO15 shoulder ball bearing 15/40/10 (A4502)

Bearing type: Shoulder bearing · Stock number: BO15 · Inner ring width: 10 mm · Manufacturer: NSK · Ball bearing closed: No · Bearing cage: Brass cage ball-guided · Area of application: Standard · Material: Brass · Material: Steel · Width: 10 mm · Surface: blank · Ø inside: 15 mm · Ø outside: 40 mm · Pony spare part no.: A4502 · Sachs spare part no.: 0932 007 001

swiing® revival intermediate slat | Puch Z50

Ø inside: 46 mm · Ø inside: 51 mm · Ø outside: 70 mm · Manufacturer: swiing® revival parts · Material: Steel · Thickness: 1.5 mm
