EL-Liq 74 from the Elring quality brand is an orange, low-strength, label-free, anaerobic sealant. It is preferably used for torsionally rigid metal flanges, e.g. housing halves on your moped, moped and small motorcycle.
Under exclusion of air and metallic contact with the connecting components, a temperature-resistant sealing film is formed which hardens.
Color: orange
Consistency: hardening
Strength: low strength
Temperature range: -55 °C to 180 °C
Maximum sealing gap: 0.35 mm
Resistance to: Mineral oils (also with additives), synthetic oils, lubricants, fuels, organic solvents and coolant additives, cold and hot water
Content: 50 ml
You can find more sealants in the accessories section.
Quality product from the German manufacturer ElringKlinger.
Technical data sheet DE
Technical data sheet FR
Technical data sheet IT
Technical data sheet EN
Safety data sheet DE
Safety data sheet FR
Safety data sheet IT
Safety data sheet EN
Details
| Temperature resistance (min.) | -55 - 180 °C |
| Manufacturer | Elring |
| Area of application | Chemistry |
| Contents [ml] | 50 ml |
| Color | orange |
| Gap dimension (max.) | 0.35 mm |
