Diaphragm seal engine Beta 521 & 512 (A8101)

Dell'Orto 12/10 SHA carburetor (replacement) | Pony Beta 521

Manufacturer: Dell'Orto · Area of application: Tuning · Nominal diameter: 12 mm · Carburetor type: SHA (type 3) · Nozzle thread: M5 · Ø fuel hose connection: 6 mm · Total length: 45 mm · Ø without reducing sleeve: 19 mm · Nozzle size: 37 · Width: 60 mm · Ø Inside entrance: 10 mm · Ø Internal connection: 16 mm · Ø Output inside: 12 mm · Height: 96 mm · Ø Air filter connection: 50.6 mm · Mounting type: Plug connection clamped · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke

Diaphragm motor Beta 521 & 512 (A8114)

Manufacturer: Pony · Area of application: Original · Mounting type: Screws · Number of flaps: 2 pcs · Membrane material: Fiberglass · Number of fixing points: 2 pcs

Intake manifold carburetor Beta 521 & 512 (A8109)

Ø inside: 12.25 mm · Manufacturer: Pony · Material: Aluminum · Area of application: Original · Mounting type: Screws · Hole spacing inlet: 35 mm · Number of fixing points: 2 pcs · Ø External connection: 16 mm

swiing® ingenious 16 mm intake manifold | Beta 521, 512

Manufacturer: swiing® ingenious parts · Area of application: Tuning · Material: Aluminum · Surface: anodized · Ø inside: 16 mm · Ø External connection: 19 mm · Color: graphite colors · Mounting type: Screws · Number of fixing points: 2 pcs · Hole spacing inlet: 35 mm

Loctite 510 sealant 50 ml

Manufacturer: Loctite · Area of application: Chemistry · Material: Silicone · Color: pink · Contents [ml]: 50 ml · Hazard warning: Causes serious eye irritation · Hazard warning: May cause allergic skin reactions · Hazard warning: May irritate the respiratory tract · Signal word: Attention · Hazard pictogram: GHS07 - Caution dangerous · Temperature resistance (min.): -55 - 250 °C · Gap dimension (max.): 0.25 mm

Dirko Dichtmasse rot (Silikon) Hochtemperatur 70 ml dauerelastisc

Manufacturer: Elring · Area of application: Chemistry · Contents [ml]: 70 ml · Hazard warning: Causes serious eye irritation · Signal word: Attention · Hazard pictogram: GHS07 - Caution dangerous · Color: red · Temperature resistance (min.): -60 - 300 °C · Gap dimension (max.): 2 mm

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Ø Stranded wire: 1.2 mm · Nipple shape: Ball · Ø nipple: 3.5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: blue galvanized · Number of components: 1 pcs · Cable length: 1650 mm

Motorex engine oil 450 ml | Pony / Cilo Beta 521 Automatic

Manufacturer: Motorex · Area of application: Gearbox lubrication with clutch · Oil type: ATF Dextron 3 (DEXIII) · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -36 - 200 °C

Engine gasket engine | Beta 521 (A8021)

Manufacturer: Pony · Material: Sealing paper · Number of components: 1 pcs · Number of fixing points: 17 pcs

Intake gasket, engine Beta 521 & 512 (A8100)

Manufacturer: Pony · Thickness: 2 mm · Material: Sealing carton · Place of use: Admission · Surface: coated · Hole spacing inlet: 35 mm

Engine clutch cover gasket | Beta 521, 512 (A8023)

Manufacturer: Pony · Material: Sealing paper · Number of components: 1 pcs · Number of fixing points: 7 pcs

Exhaust gasket exhaust | Beta 521 & 512 (A8099)

Manufacturer: Pony · Ø inside: 21.8 mm · Material: Sealing carton · Material: Sheet metal (steel) · Area of application: Standard · Reinforced: Yes · Thickness: 1.7 mm · Place of use: Exhaust · Ø screw holder: 6 mm

Diaphragm motor Beta 521 & 512 (A8114)

Manufacturer: Pony · Area of application: Original · Mounting type: Screws · Number of flaps: 2 pcs · Membrane material: Fiberglass · Number of fixing points: 2 pcs

swiing® ingenious 16 mm intake manifold | Beta 521, 512

Manufacturer: swiing® ingenious parts · Area of application: Tuning · Material: Aluminum · Surface: anodized · Ø inside: 16 mm · Ø External connection: 19 mm · Color: graphite colors · Mounting type: Screws · Number of fixing points: 2 pcs · Hole spacing inlet: 35 mm

Dell'Orto 16/16 SHA carburetor hand choke | Beta 521 & 512

Manufacturer: Dell'Orto · Total length: 82 mm · Camouflaged: No · Area of application: Tuning · Material: Aluminum · Width: 69 mm · Carburetor type: SHA (type 4) · Nominal diameter: 16 mm · Ø Internal connection: 19 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 16 mm · Ø Output inside: 16 mm · Color: black · Ø Air filter connection: 59 mm · Mounting type: Plug connection clamped · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle thread: M5 · Nozzle size: 82 · Height: 83 mm

swiing® ingenious intake manifold & carburetor 16 mm tuning set | Beta 521 & 512

Manufacturer: Dell'Orto · Manufacturer: swiing® ingenious parts · Camouflaged: No · Area of application: Tuning · Carburetor type: SHA (type 4) · Nominal diameter: 16 mm · Ø Internal connection: 18 mm · Ø without reducing sleeve: 21 mm · Ø Inside entrance: 16 mm · Ø Output inside: 16 mm · Ø Air filter connection: 59 mm · Mounting type: Flange · Mounting type: Plug connection clamped · Ø fuel hose connection: 6 mm · Choke control: Hand choke · Nozzle thread: M5 · Nozzle size: 82
