Crank cover 4-edge Pony GTX / Cross 521 (P8083)

Union pedals plastic standard

Width: 77 mm · Manufacturer: Union · Material: Plastic · Material: Steel · Surface: rubberized · Thread type: FG14.3 (9/16" 20G) · Drive: Hexagon socket · Drive: Outer edge · Color: black · Width across flats SW: 15 mm · Height: 29 mm · Reflectors: Yes · Total length: 129 mm

Union pedals solid black

Width: 64 mm · Manufacturer: Union · Material: Rubber · Material: Steel · Surface: galvanized (blue) · Surface: rubberized · Thread type: FG14.3 (9/16" 20G) · Drive: Hexagon socket · Drive: Outer edge · Color: black · Color: silver · Width across flats SW: 15 mm · Height: 34 mm · Reflectors: Yes · Total length: 131 mm

GPO pedal crank left black (square) | Pony (P8082)

Manufacturer: GPO · Surface: varnished · Color: black · Crank length (center-center): 155 mm · Total length: 180 mm · Wide intake: 13 mm · Cranking (offset): 34 mm

GPO pedal crank right black (square) | Pony (P8081)

Manufacturer: GPO · Surface: varnished · Color: black · Crank length (center-center): 155 mm · Total length: 180 mm · Wide intake: 13 mm · Cranking (offset): 34 mm

Screw M8x1 x 20 Tretwerk | Pony / Cilo Beta 521 (P8089)

Manufacturer: Pony · Thread type: MF8x1 (fine pitch thread) · Drive: External hexagon · Screw head: Hexagon · Thread length: 20 mm

GPO pedal crank left chrome 157 mm strong cranked, angular

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Color: Chrome · Total length: 157 mm · Crank length (center-center): 132 mm · Ø Pedal wedge: 9.5 mm · Cranking (offset): 39 mm · Thread type: FG14.3 (9/16" 20G)

GPO pedal crank right chrome 157 mm strong cranked, angular

Manufacturer: GPO · Surface: chrome-plated · Color: Chrome · Total length: 157 mm · Crank length (center-center): 132 mm · Ø Pedal wedge: 9.5 mm · Cranking (offset): 39 mm

KMC drive chain 415H (reinforced) 128L

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Manufacturer: KMC · Material: Steel · Surface: blank / oiled · Number of chain links: 128 pcs · Rolling circumference: 1626 mm · Chain lock type: Spring lock · Color: gray · Ø bore: 4 mm · Ø Pin: 3.94 mm

Gas cable Ø 1.2 mm x 165 cm (nipple ball) Dell'Orto

Ø nipple: 3.5 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Ø Stranded wire: 1.2 mm · Cable length: 1650 mm · Nipple shape: Ball · Number of components: 1 pcs

Union pedals plastic standard

Width: 77 mm · Manufacturer: Union · Material: Plastic · Material: Steel · Surface: rubberized · Thread type: FG14.3 (9/16" 20G) · Drive: Hexagon socket · Drive: Outer edge · Color: black · Width across flats SW: 15 mm · Height: 29 mm · Reflectors: Yes · Total length: 129 mm

Motorex engine oil 450 ml | Pony / Cilo Beta 521 Automatic

Manufacturer: Motorex · Area of application: Gearbox lubrication with clutch · Oil type: ATF Dexron 3 (DEXIII) · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -36 - 200 °C

ESJOT sprocket 42 teeth 4/5/6 hole Ø 98 mm cranked black

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Thickness: 4.3 mm · Manufacturer: ESJOT · Material: Steel · Surface: powder-coated · Number of teeth: 42 pcs · Color: black · Number of fixing points: 4 pcs · Number of fixing points: 5 pcs · Number of fixing points: 6 pcs · Ø inside: 98 mm · Ø bolt circle: 115 mm · Ø mounting hole: 6.5 mm · Cranking (offset): 12 mm

GPO pedal axle 24 teeth square | Pony GTX Beta 512, 521 (P1210)

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Color: Chrome · Number of teeth: 24 pcs · Total length: 306 mm · Wavelength from wreath: 122 mm · Wavelength from wreath: 178 mm · Ø Outer sprocket: 102.3 mm

GPO pedal axle 30 teeth (square) | Pony / Cilo Cross Beta 521

Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Number of teeth: 30 pcs · Color: Chrome · Total length: 306 mm · Wavelength from wreath: 124 mm · Wavelength from wreath: 178 mm · Ø Outer sprocket: 128.2 mm

Cover / plug 21.1 mm

Material: Rubber · Clamping diameter: 21.1 mm · Color: black

Bottom bracket bushing | Pony / Cilo Beta 521 (P8065)

Manufacturer: Pony · Material: Polyoxymethylene (POM) · Bearing type: Plain bearing · Color: black · Ø inside: 16.5 mm · Ø outside: 21 mm

Distance bushing pedal axle 16.3/25.2/9.3 | Pony GTX 521, Cross 521 (P8102)

Manufacturer: Pony · Material: Polyoxymethylene (POM) · Nominal diameter inside: 16 mm · Ø inside: 16.3 mm · Ø outside: 25.2 mm · Total length: 9.3 mm
